Superior Line Grinding wheel for Metal

Featues:
● Heat Treated aluminum oxide mix Zirconia grain
● Double glass fibre nets
● A24 S-BF hard bond
● T41 Flat center and T42 depressed center
Benefits
● Industry performance,Outstanding service life
● Aggressive stock removal rate
● Low-burr edges
Application
● For all metal grinding application
Description
Comments
Diameter
Diameter
Speed
Box
Shape
Art No.
Bar code
[Inch]
[mm]
[r.p.m]
[pcs]






4x1/4x5/8
100x6.4x16
15200
25
11154
69458268 11154
4.5x1/4/x7/8
115x6.4x22
13300
25
11161
69458268 11161
5x1/4x7/8
125x6.4x22
12200
25
11178
69458268 11178
6x1/4x7/8
150x6.4x22
10200
25
11185
69458268 11185
7x1/4x7/8
180x6.4x22
8600
25
11192
69458268 11192
9x1/4x7/8
230x6.4x22
6600
25
11208
69458268 11208

Name:Diamond
Time:2012-12-16
Message:
Diamond wheel grinding with what?
Replay:
Diamond grinding wheel you mean or shaping, grinding wheel dressing dressing is generally a little soft the ordinary grinding wheel as corundum class of grinding diamond wheel to remove the binder or high-speed grinding wheel sandblasting diamond grinding wheel bond relatively diamond edge low and exposed diamond cutting edge and to enhanced diamond wheel Paixie purpose of dressing, if shaping and dressing generally depending on the combination of the diamond wheel etc. electrolytic grinding machine by making good the The required type graphite electrode surface directly grinding wheel molding (metal bond diamond wheel) or direct use of forming diamond wheel directly molded trim (resin diamond wheel).
